SONY FCB-EX12EP 1/4-Type 12x IS CCD Block Camera Module from Ryfutone Co.,LTD

SONY FCB-EX12EP 1/4-Type 12x IS CCD Block Camera Module from Ryfutone Co.,LTD

The Sony FCB-EX12EP Camera is a 12x block camera with superb picture quality and features you've come to expect from the FCB camera line-up, such as digital output, color enhancement and sodium vapor lamp mode.
HIGHLIGHTS:
*  Digital Output (ITU-R BT656):
  By using the digital interface, the quality of the camera video signal is maintained with minimal deterioration. This can lead to cost savings due to the direct connection to codecs/systems without the need for any additional components.
*  Temperature Readout:
  The value of the internal temperature of the SONY FCBEX12E / SONY FCB-EX12EP camera can be read out via the VISCA  protocol. When checking the internal temperature of equipment (i.e., speed dome unit), it is possible to use this data to turn a fan or heater on/off inside the equipment as needed.
*  Color Enhancement:
  Ideally suited for low vision applications, new color enhancement options can make reading text and pictures less challenging. Available options include monochrome, binary, inverted and enhanced color modes.
*  White Balance: Outdoor Auto Mode:
  The SONY FCB-EX12EP/SONY FCB-EX12E camera is equipped with a new Outdoor Auto Mode feature. When shooting at dawn or dusk, images could appear bluish. The new E version cameras automatically adjust the white balance to reduce the dark tones at dawn or dusk.
*  White Balance: Sodium Vapor Lamp Mode:
  When cameras are shooting under a sodium vapor lamp (typically a street lamp or tunnel lamp), the image could appear to have a yellowish tint. The new SONY FCB-EX12EP / FCB-EX12E camera is equipped with a new Sodium Vapor Lamp Mode that automatically compensates for the sodium vapor lamp degree of Kelvin to restore objects to their original color.

SPECIFICATIONS
CAMERA
*  Image Device: 1/4-type EXview HAD CCD (PS)
*  Effective Pixels: 380,000
*  Digital Zoom: 12x (144x with optical zoom)
*  Horizontal Viewing Angle: 53.6 (wide end) to 4.6(tele end)
*  Minimum Object Distance: 10 mm* (wide) ~ 800 mm (tele) *Default: 290 mm
*  Sync System: Internal/External (V-lock)
*  Electronic Shutter: 1/1 to 1/10,000 s, total 22 steps
*  White Balance: Auto. ATW, Indoor, Outdoor, Outdoor Auto, Sodium Vapor Lamp (Fix/Auto), One-push, Manual
*  Gain: Auto/Manual/Max. Gain Limit (-3 to +28 dB, +2 dB step/total 16 steps)
*  Wide Dynamic Range: No
*  Privacy Zone Masking: Spherical
*  Character Generator: Yes (English/Chinese)
*  Focus System: Auto (Sensitivity: normal, low), One-push AF, Manual, Infinity, Interval AF, Zoom Trigger AF, Focus compensation in ICR On
*  Picture Effects: E-flip, Nega Art, Black & White, MirrorImage, Color Enhancement
*  Exposure Control: Auto, Manual, Priority Mode (shutter priority & iris priority), Bright, EV Compensation, Slow AE
VIDEO OUTPUT*  Lens Value: 12x optical zoom lens, f=3.7 mm (wide) to 44.4 mm (tele), F1.6to F2.5
*  S/N Ratio: More than 50 dB
*  Minimum Illumination: Approx. 1.0 lx (F1.6, 50 IRE)
*  Video Output: Analog: VBS: 1.0 Vp-p (sync negative)
*  Horizontal Resolution: 550 TV Lines
INTERFACE
*  Camera Control Interface: VISCA? protocol (CMOS 5 V) 9.6 Kbps, 19.2 Kbps, 38.4 Kbp; Stop bit, 1 bit
GENERAL*  Dimensions (W x H x D): 44.8 x 46.9 x 71.8 mm
*  Weight: Less than 150 g
*  Operating Temperature: -5 ~ 60 degrees
*  Storage Temperature: -20? ~ 60 degrees
*  Power Consumption: 3.0 W (motors active) / 1.9 W (motors inactive)
*  Power Requirements: 6.0 V ~12.0 V DC

Sony CCTV Camera Zoom Module FCB-EX490EP CCD Colour Analog Camera Module from Ryfutone Co.,LTD

Sony CCTV Camera Zoom Module FCB-EX490EP CCD Colour Analog Camera Module from Ryfutone Co.,LTD



SONY FCB-EX490EP Camera Description:
The SONY FCB-EX490EP block camera combines superb picture quality with high zoom capabilities, up to 216x with optical zoom. Ideally suited for IP-ready monitoring applications, the Sony FCB-EX490EP incorporates True Progressive Scan with a digital output (ITU-R BT656). In low or high contrast lighting situations, the Sony FCB-EX490EP operates an Auto Wide-D mode that automatically turns on/off the Wide-D according to the luminance of the image. In addition, color enhancement features are ideally suited for low vision applications.

SONY FCB-EX490EP Specifications:
* Image Device: 1/4-type EXview HAD™ CCD (Progressive Scan)
* Effective Pixels: 380,000
* Digital Zoom: 12x (216x with optical zoom)
* Horizontal Viewing Angle: 48.0° (wide end) to 2.8° (tele end)
* Minimum Object Distance: 10 mm* (wide) ~ 800 mm (tele) *Default: 290 mm
* Sync System: Internal/Ecternal (V-lock)
* Electronic Shutter: 1/1 to 1/10,000 s, 22 steps
* White Balance: Auto, ATW, Indoor, Outdoor Auto, Sodium Vapor Lamp (fix/auto), One-push, Manual
* Gain: Auto/Manual?max. Gain Limit (-3 to 28 dN, 2 dB steps)
* EV Compensation: Yes
* Wide Dynamic Range: Auto Mode, IS/PS Mode
* Privacy Zone Masking: Spherical
* Character Generator: Title: 20 characters/line, max. 11 lines
* Picture Effects: E-Flip, Nega Art, B/W, Mirror Image, Color Enhancement
* Exposure Control: Auto, Manual, Priority Mode (shutter priority & iris priority), Bright, EV Compensation, Slow AE

SONY FCB-EX490EP Video Output Specifications:* Lens Value: 18x optical zoom f=4.1 mm (wide) ~73.8 (tele)
* S/N Ratio More than 50 dB
* Minimum Illumination: 0.7 lx (typical) (F1.4, 50 IRE)
* Video Output: Analog: VBS: 1.0 Vp-p (sync negative), Y/C; Digital: Y/CB/CR 4:2:2 (ITU-R BT656 Style)
* Signal System: NTSC (FCBEX490E/FCB-EX490E), PAL (FCBEX490EP/FCB-EX490EP)
* Horizontal Resolution: 550 TV Lines
Interfaces Specifications:
* Camera Control Interface VISCA (TTL signal level) Baud Rate: 9.6Kb/s, 19.2Kb/s, 38.4Kb/s; Stop bit: 1/2 bit selectable

SONY FCB-EX490EP General Specifications:* Dimensions (W x H x D): 52.0 x 57.5 x 88.5 mm
* Weight: 230 g
* Operating Temperature: -5° C to 60° C
* Power Consumption: 2.6 W (motors active 4.4 W)

Sony CCTV Camera Zoom Module FCB-EX11DP Colour CCD Block Camer from Ryfutone Co.,LTD

Sony CCTV Camera Zoom Module FCB-EX11DP Colour CCD Block Camer from Ryfutone Co.,LTD

Description:
The new ultra-compact and lightweight SONY FCB-EX11DP camera is specifically designed for easy integration into mini-dome housings for superb observation. Its outstanding picture quality, excellent auto-focus performance and small size make it the ideal contender in space restricted environments such as underground inspection systems of oil gas pipes, low vision systems, police vehicles and more. The FCB-EX11DP incorporates a 1/4-type EXview HAD CCD™ sensor and is equipped with a 10x optical zoom lens that can provide a 120x zoom ratio when combined with the digital zoom. In addition, the FCB-EX11DP color block camera inherits many of the excellent features found in Sony's new FCB D version cameras such as slow AE Response, Advanced Spherical Privacy Zone Masking and Multi-line on-screen display. With its excellent picture quality, compact size and feature-rich design, the SONY FCB-EX11DP is ideal for a wide range of applications.

FEATURES:
* High Resolution of 530 TV Lines - The SONY FCB-EX11DP camera incorporates a ¼-type EXview HAD™ CCD with an Advanced Digital Signal Processor (DSP) to reproduce clear, detailed images at an extremely high horizontal resolution of 530 TV lines.
* Powerful & Versatile Zoom Capability - The SONY FCB-EX11DP camera is equipped with a 10x optical zoom lens, allowing for a zoom capability of up to 120x when used in combination with its 12x digital zoom.
* Video Motion Detection - As with Sony's FCB D version cameras, the new SONY FCB-EX11DP camera features a motion detection function. When motion is detected within an area of the picture designated by the user, an alarm signal is output via the camera's control interface using the VISCA™ protocol. Users can designate up to four detecting areas freely from any 8 vertical and 12 horizontal blocks. The video motion detection function is useful for unattended monitoring/recording found in security applications.
* Slow AE Response Function - The SONY FCB-EX11DP is equipped with a slow AE response function to automatically slow the rate at which the camera's exposure levels change. The rate can be set up to 32 times slower than when Full-Auto AE or Priority (shutter/iris) modes are selected. This function is useful when monitoring areas in which lighting conditions abruptly change.
* Advanced Spherical Privacy Zone Masking with Mosaic Effect - Unwanted or prohibited areas within an image can be masked precisely and appropriately with either a solid color or a mosaic effect. When the SONY FCB-EX11DP is integrated into a P/T/Z Camera system, this technology can keep masking areas interlocked with P/T/Z movements regardless of the camera angle.
* Multi-line On-screen Display - Up to eleven lines with 20 characters per line can be displayed on the SONY FCB-EX11DP monitoring screen using VISCA™ commands. Captions can be displayed on the screen to provide operators with a user-friendly interface.

SPECIFICATIONS:
The SONY FCB-EX11DP Camera:* Backlight Compensation On/Off
* Character Generator OSD: 11 Lines (20 characters per line)
* Camera Mode display: ON/OFF
* Digital Zoom 12x (120x with optical zoom)
* EV Compensation -10.5 to 10.5 dB (1.5 dB steps)
* Effective Pixels Approx. 380000 pixels
* Electronic Shutter 1 to 1/10000 s, 22 steps
* Exposure Control: Auto, Manual, Priority Mode, Bright, EV Compensation, Backlight * Compensation, Slow AE, Flicker Cancel Auto
* Focus System: Auto (Sensitivity: normal and low), One-push AF, Manual, Infinity, * Interval AF, Zoom Trigger AF
* Gain Auto / Manual (-3 to 28 dB 2 dB steps)
* Horizontal Viewing Angle 46° (wide) to 4.6° (tele)
* Image Device 1/4-type EXview HAD CCD
* Minimum Object Distance 200 mm (wide); 1.0 m (tele)
* Picture Effects: E-Flip, Nega Art, Black & White, Mirror Image
* Privacy Zone Masking On / Off (24 positions)
* Sync System Internal/External (V-lock)
* White Balance: Auto, ATW, Indoor, Outdoor, One-push, Manual

SONY FCB-EX11DP General
* Dimensions (W x H x D) 1 7/16 x 1 5/8 x 2 3/8 inches (35.9 x 40.8 x 59.2 mm)
* Operating Temperature 32 to 122 °F (0 to 50 C°)
* Power Consumption 1.9 W (motors inactive); 2.8 W (motors active)
* Power Requirements DC 6 to 12 V
* Storage Temperature -4 to 140 °F (-20 to 60 C°)
* Weight 3.3 oz (95 g)

SONY FCB-EX11DP Interfaces
* Camera Control Interface VISCA (TTL signal level); Baud rate: 9.6 Kb/s; 19.2 Kb/s; 38.4 Kb/s; 1 or 2 Stop bit selectable

SONY FCB-EX11DP Video Output
* Horizontal Resolution On/Off (On: 530 TV lines)
* Horizontal Resolution Value 530 TV Lines
* Lens Value 10x
* Minimum Illumination 1.0 lux
* S/N Ratio More than 50 dB
* Video Output VBS: 1.0 Vp-p (sync negative); Y/C

SONY FCB-EX1020P 36x Zoom Color Block Camera Module from RYFUTONE Co.,LTD

SONY FCB-EX1020P 36x Zoom Color Block Camera Module from RYFUTONE Co.,LTD

Description: The Sony FCB-EX1020P Color Block Camera with True Progressive Scan Technology with Exceptional Picture Quality and High Zoom Capabilities for Traffic and Surveillance Monitoring, Video Conferencing and Low Vision applications. Sony continues to prevail on the cutting edge of the imaging industry with the latest addition to the FCB camera series. The SONY FCB-EX1020 (NTSC) and FCB-EX1020P (PAL) color block camera incorporates a 1/4 type ExView HAD™ CCD and features True Progressive Scan with exceptional picture quality and high zoom capabilities - 432x combined digital and optical zoom. In addition, the Sony FCB-EX1020 and FCB-EX1020P(FCBEX1020P) Camera is the first in this exceptional camera series with IP-Ready digital output, uniting several new and upgraded features with its renowned FCB performance and outstanding picture quality. SONY FCB-EX1020P Camera Specifications: * Image Device: 1/4 type EXview HAD™ CCD (Progressive Scan) * Effective Pixels: 380,000 * Digital Zoom: 12x (432x with optical zoom) * Horizontal Viewing Angle: 57.8° (wide end) to 1.7° (tele end) * Sync System: Internal/External (V-lock) * Electronic Shutter: 1/1 to 1/10,000 s, 22 steps * White Balance: Auto, ATW, Indoor, Outdoor, One-push, Manual * Gain: Auto/Manual (-3 to 28 dB, 2dB steps) * Wide Dynamic Range: Auto Mode IS/PS Mode * Backlight Compensation: On/Off * Privacy Zone Masking: On/Off (24 positions, 8 positions per screen) 14 Colors + Mosaic * Character Generator: Mode: On/Off (White Balance, Gain, etc.); Title: 11 Lines (20 characters per line) * Flicker Cancel: Auto * Focus System: Auto (Sensitivity: normal, low), One-push AF, Manual, Infinity, Interval AF, Zoom trigger AF * Camera Operation / Zoom Switch: Zoom Tele, Zoom wide * Picture Effects: E-flip, Nega Art, Black & White, Mirror Image, Color Sony FCB-EX1020P Video Output Specifications:* Lens Value: 36x optical zoom * S/N Ratio: More than 50 dB * Minimum Illumination: 1.4 lx (typical) (F1.6, 50 IRE) * Video Output: VBS: 1.o Vp-p (sync negative); Y/C * Signal System: NTSC (FCBEX1020/FCB-EX1020), PAL (FCBEX1020P/FCB-EX1020P) * Horizontal Resolution: 540 TV Lines Sony FCB-EX1020P Interfaces Specifications:* Camera Control Interface: VISCA (TTL signal level) Baud Rate: 96Kb/s, 19.2 Kb/s, 38.4 Kb/s; Stop bit: 1/2 bit selectable Sony FCB-EX1020P General Specifications: * Dimensions (W x H x D): 50.0 mm x 57.5 mm x 87.9 mm * Weight: 230 g * Operating Temperature: -5° C to 60° C (32° to 122° F) * Storage Temperature: -20° to 60° C (-4° to 140° F) * Power Consumption: 6 to 12 V DC/ 3.0 W (motors inactive, 4.0 W (motors active)

Panasonic GP-MH310 HD Video conferencing Camera 4 Megapixels 10X Zoom Module Camera

Panasonic GP-MH310 HD Video conferencing Camera 4 Megapixels 10X Zoom Module Camera

GP-MH310 Specifications :

Video Output	HD (LVDS) 1080/60i, 1080/30p, 720/60p 1080/50i, 1080/25p, 720/50p
Image Sensor	1/2.5 type MOS
Effective Pixels (approx.)	4 Megapixels
Scanning Mode	Progressive Scan
Minimum Illumination	Color: 2.0lx (1/30sec, 50IRE, F1.8) B/W: 0.1lx (1/30sec, 50IRE, F1.8)
Video S/N Ratio	More than 50 dB
Synchronization	Internal Sync
Electronic Shutter	1/50 (1/60), 1/120 (1/100), 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000
Focal Length	6.3 mm ~ 63 mm, F1.8-2.5
Zoom	10x Optical Zoom, 16x Digital Zoom
Field of View	H: (16:9) 5.5°~ 50.6°, V: (16:9) 3.1°~ 29.3°
Power Supply	6-12V DC 3.6W (4.2W, motor active)
Dimensions (approx.)	(W x H x L) 43.7 mm x 44.2 mm x 75.2 mm (1.7 inch x 1.7 inch x 2.9 inch)
Weight (approx.)	180 g (6.35 oz)

The Single Chip Full HD Module Camera from Panasonic brings you outstanding HD resolution and superior color performance at the right price, and the right size for a wide variety of medical & industrial applications. With outstanding performance, the camera delivers native 1080p/60p resolution, plus multi-format capability in a compact and lightweight camera module.


The Panasonic GP-MH310 Features:
* Flexible HD interface: HD (LVDS), Component Y/Pb/Pr, YC output (SD)
* Newly-developed 1/2.5 4 mega-pixels HD MOS sensor
* Image Stabilizer
* Auto Focus
* Day/Night function
* Compact Design (43.7 mm x 44.2 mm x 75.2)
* 10x Optical Zoom, 16x Digital Zoom
* Degradation-free LVDS digital transmission
Applications:
* Inspection
* Video conferencing
* Security
* Traffic control
* Un-manned vehicles
* In-car video

http://www.accessories-shops.com/panasonic-camera/panasonic-gp-mh310-hd-video-conferencing-camera-4-megapixels-10x-zoom-module-camera.html

SONY FCB-MA130 16X Zoom HD Compact Color Camera SONY Mini HD Camera

SONY FCB-MA130 16X Zoom HD Compact Color Camera SONY Mini HD Camera

*  Sony FCB-MA130 16x Zoom HD Compact Color Camera
*  1920 pixels x 1080p
*  1/2.45"-type CMOS
*  16x Digital Zoom, 30fps
*  (F2.8) Full High Definition Block Camera
*  Small form factor 16.5x10.3x18.0 mm
*  Image Stabilizer
*  Face Detection
*  Wide Dynamic Range (ATR)
*  Noise Reduction (3DNR)
Sony is expanding its popular FCB Block Camera Series with the introduction of an ultra-compact, all-in-one color camera – the FCB-MA130 – which supports both moving pictures and still images.
Colour Block CameraWith its modest dimensions, the FCB-MA130 contributes to reducing the size of finished products, and this can be useful in wide range of applications. Incorporating a 1/2.45-type Exmor™ CMOS sensor and Sony's original image signal processor, this new camera enables users to capture Full HD resolution (1080p/30) movies and 13-megapixel still images. The FCB-MA130 features several other useful functions, including embedded Image Stabilizer and Face Detection, thanks to Sony's original image signal processor. Outstanding compactness coupled with high-quality images – with these capabilities, Sony anticipates this remarkable camera is set to open up brand new industrial applications.
The FCB-MA130 enhances the current collection with its highly compact size (16.5 x 10.3 x 18.0 mm) and high-quality images. With the ability to capture Full High Definition (1080p/30) moving pictures, this micro camera offers more solutions for a wide variety of industrial applications.

SONY FCB-MA130 Specifications:
*  Image sensor:  1/2.45-type Exmor CMOS
*  Standard output pixels:  Approximately 13 Megapixels
*  Signal System (movie):  1920 x 1080 (FHD), 1600 x 1200 (UXGA), 1280 x 960 (SXGA), 1280 x 720 (HD), 1024 x 768 (XGA), 800 x 480 (WVGA), 640 x 480 (VGA); 30fps/25fps*
*  Signal System (still):  4192 x 3104, 4128 x 3096 (13M), 3264 x 2448 (8M), 2592 x 1944 (5M), 1920 x 1080 (FHD), 1280 x 960 (SXGA), 1280 x 720 (HD), 640 x 480 (VGA)
*  Digital Zoom:  16x
*  Angle of View:  H: Movie Mode: 53°, Still Image Mode: 58° (720p/1080p modes)
*  Lens:  F2.8
*  Gain:  Auto
*  Focus:  One-push AF
*  Object Distance:  Minimum 100mm
*  Exposure Control:  Auto, Hold, Manual, Shutter priority, Gain priority
*  Shutter speed:  1/25 to 1/5000 s, total 24 steps
*  Sync System:  Internal
*  AE Control:  Auto, Hold, Manual, Shutter priority, Gain priority
*  Backlight Correction:  Yes
*  White Balance:  Auto, Hold, ATW, Fixed (light bulb, neutral color fluorescent light, clear sky, cloudy sky, daylight color fluorescent light, light bulb color fluorescent light)
*  Video Output:  CMOS Clock 81MHz, Parallel 16bit (YCbCr422 / SAV, EAV selectable) / Sync Signal (HD, VD)
MIPI D-PHY Clock 324MHz, Data 2lane CSI-2 (YCbCr422)
*  Camera Features:  ATR, Noise Reduction, Image Stabalization for image and movie, Face Detection, Picture Effects (Flip horizontal, Flip vertical)
*  Picture Effects:  Flip Horizontal, Flip Vertical
*  Power requirements:  3.3±0.1, 1.8±0.1, 1.2-0.05/+0.1 V DC
*  Power consumption:  700 mW (at FHD movie)
*  Operating temperature:  -5° C to +50°C; 23°F to 122°F
*  Storage temperature:  -20°C to +60°C; -4°F to +140°F
*  Operating humidity:  20% to 80%
*  Storage humidity:  20% to 95%
*  Dimensions (W x H x D):  16.5 x 10.3 x 18.0 mm; 21/32 x 13/32 x 23/32 inches
*  Mass:  Approx. 2.2 g; 0.078 oz

2.5 inch TFT LCD screen portable mini DVR recorder police body camera with remote control

2.5 inch TFT LCD screen portable mini DVR recorder police body camera with remote control

The RFT-EAYE316 professional collection of image through special transmission line and can hanging in waist between of digital memory connection, side shooting side storage, can received all monitoring camera, storage of picture distribution has run seconds remember number device, has not change sex, makes shooting content has very powerful of evidence role, this species equipment of advantages is volume small, and weight light, operation convenient, function strong, can as engineering treasure, test signal of preferred, control very flexible, a key type switch. Restore clear sound image without any compression, storage format do not have to edit that can burn discs, mini Digital storage device is now equipped with the professional field.
Product Features: 1. Multiple record model: Motion detect rocord/manual record
2. Storage full over write automatically
3. Fast video recording by one key function
4. Recording,power ON/OFF via remote control
5. 960*240 high-definition 2.5/2.7-inch LCD screen
6. Support 32GB TF memory card
7. Video resolution : 800*600/640*480/*320*240 optional
8. Video frames 10-30frames/second optional
9. High-speed USB2.0 interface
10. Audio and video input/output
11. Configuration removable high-capacity lithium battery, 5hours of continuous playback, video recording up to 2hours standby
Technical parameters:* Image device: 1/4 " CMOS
* Sensing Area: 4.9mm*3.7mm
* Horizontal resolution: 600TVL
* Minimum illumination: 0.1LUX
* CCD aperture: 1/50 (1/60)-100,000 (seconds)
* S/N ratio: more than 48db
* Minimum illumination: F1.2, 0.05Lux
* Video output: 1.0Vp-p,75 Euro
* Socket : VIDEO OUT 75 Ohm
* Power supply : DC5V
* Power consumption: 600mA
* Lens angle: 90 degree wide angle
Parameters:LCD: 2.5inch TFT LCD
Video output mode: NTSC/PAL
Video mode: NTSC/PAL
Resolution: 800*600/640*480/320*240
Video format: AVI
Frequency range: 20Hz-20KHz
Output channel: Stereo
Headphone output: L20mW+R20mW[16O] (Max volume)
Speaker: 1.5W
Compatible memory card : TF memory card
USB: USB2.0
Power: DC5V 2A
Built-in battery: Li-on battery 1800Mah
Recording time: >=2 hour
Play time: >=5 hour
Package: (not including memory cards)
* CCD camera x 1
* Digital video recorder x 1
* remote control x 1
* USB cable x 1
* AV cable x 1
* Charger x 1
* Battery x 1
